首頁進口晶振KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振

KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振

頻率：50.000MHZ
尺寸：3225
應　用： KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振,憑借高精度,寬溫域,小型化,強抗干擾的綜合優勢,廣泛應用于多領域高端電子設備.在消費電子領域,可作為智能手機射頻芯片,平板電腦處理器,智能手表主控單元的時鐘...

KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振
KC3225A50.0000C3GE00是日本京瓷(Kyocera)品牌推出的高性能進口晶振,核心頻率精準設定為50.0000MHz,為電子設備提供穩定且高精度的時鐘信號,是設備時序控制的核心組件.該型號采用標準3225貼片進口晶振封裝規格,尺寸為長3.2mm×寬2.5mm,超薄的封裝設計(厚度通?？刂圃?.7mm以內),能靈活適配智能手機,智能穿戴設備,物聯網模塊等對元器件體積要求嚴苛的小型化產品.工作溫度范圍覆蓋-40℃至+85℃,可在高低溫交替的復雜環境中保持穩定運行,同時具備低功耗特性,有效降低設備整體能耗,延長便攜式電子設備的續航時間,滿足多場景下的使用需求.

KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振

原廠型號 Originalmodel：	KC3225A50.0000C3GE00	品牌brand：	京瓷Kyocera
Manufacturer品牌	日本京瓷晶振	OperatingTemperature溫度	-40+85℃
Series型號	KC3225A	Current-Supply(Max)	-
Type類型	XO	PackageHeight高度	0.89mm
Frequency頻率	50M	Termination 腳位	4-pad
輸出方式 Output：	CMOS	PackageType 封裝類型	4-Smd
Voltage-Supply電壓	3.3V	Packaging 包裝	TapeandReel
FrequencyStability頻率穩定度	50PP	安裝方式 Installation：	Surfacemount
Size/Dimension尺寸	3225mm	最小包裝數MPQ：	3000

KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振

KC3225A50.0000C3GE00,京瓷Kyocera晶振,3225日本進口晶振

CX2520DB40000D0FLJCC	日產京瓷晶振	CX2520DB	40 MHz	±15ppm	±10ppm	8pF	50 Ohms
CX2520DB16000D0GEJCC	日產京瓷晶振	CX2520DB	16 MHz	±15ppm	±15ppm	8pF	80 Ohms
CX2520DB24000D0GEJCC	日產京瓷晶振	CX2520DB	24 MHz	±15ppm	±15ppm	8pF	80 Ohms
CX2520DB24576D0GEJCC	日產京瓷晶振	CX2520DB	24.576 MHz	±15ppm	±15ppm	8pF	80 Ohms
CX2520DB32000D0GEJCC	日產京瓷晶振	CX2520DB	32 MHz	±15ppm	±15ppm	8pF	50 Ohms
CX2520DB48000D0GEJCC	日產京瓷晶振	CX2520DB	48 MHz	±15ppm	±15ppm	8pF	50 Ohms
CX2520SB13560D0GEJCC	日產京瓷晶振	CX2520SB	13.56 MHz	±15ppm	±15ppm	8pF	150 Ohms
ST3215SB32768E0HPWBB	日產京瓷晶振	ST3215SB	32.768 kHz	±200ppm	±20ppm	9pF	70 kOhms
ST2012SB32768Z0HPWB4	日產京瓷晶振	ST2012SB	32.768 kHz	-	±20ppm	4pF	75 kOhms
ST2012SB32768C0HPWBB	日產京瓷晶振	ST2012SB	32.768 kHz	-	±20ppm	7pF	80 kOhms
ST2012SB32768E0HPWBB	日產京瓷晶振	ST2012SB	32.768 kHz	-	±20ppm	9pF	80 kOhms
ST3215SB32768Z0HPWBB	日產京瓷晶振	ST3215SB	32.768 kHz	-	±20ppm	4pF	70 kOhms
CX2016DB16000D0FLJCC	日產京瓷晶振	CX2016DB	16 MHz	±15ppm	±10ppm	8pF	200 Ohms
CX5032GB08000H0HPQZ1	日產京瓷晶振	CX5032GB	8 MHz	±30ppm	±20ppm	12pF	300 Ohms
CX5032GB10000H0HPQZ1	日產京瓷晶振	CX5032GB	10 MHz	±30ppm	±20ppm	12pF	150 Ohms
CX5032GB12000H0HPQZ1	日產京瓷晶振	CX5032GB	12 MHz	±30ppm	±20ppm	12pF	150 Ohms
CX5032GB16000H0HPQZ1	日產京瓷晶振	CX5032GB	16 MHz	±30ppm	±20ppm	12pF	100 Ohms
CT2520DB26000C0FZZA1	日產京瓷晶振	CT2520DB	26 MHz	±10ppm	±10ppm	7pF	30 Ohms
CX2520DB12000C0WLSC1	日產京瓷晶振	CX2520DB	12 MHz	±50ppm	±50ppm	7pF	100 Ohms
CX2520DB38400D0FZGC1	日產京瓷晶振	CX2520DB	38.4 MHz	±11ppm	±10ppm	8pF	80 Ohms
CX3225SB48000D0FPJC2	日產京瓷晶振	CX3225SB	48 MHz	±15ppm	±10ppm	8pF	50 Ohms
CX3225SB48000D0WPSC2	日產京瓷晶振	CX3225SB	48 MHz	±30ppm	±15ppm	8pF	50 Ohms
CX3225SB54000D0FPJC2	日產京瓷晶振	CX3225SB	54 MHz	±15ppm	±10ppm	8pF	50 Ohms
CX3225SB54000D0WPSC2	日產京瓷晶振	CX3225SB	54 MHz	±30ppm	±15ppm	8pF	50 Ohms
ST3215SB32768B0HSZA1	日產京瓷晶振	ST3215SB	32.768 kHz	-	±20ppm	6pF	70 kOhms
ST3215SB32768C0HSZA1	日產京瓷晶振	ST3215SB	32.768 kHz	-	±20ppm	7pF	70 kOhms
ST3215SB32768E0HSZB1	日產京瓷晶振	ST3215SB	32.768 kHz	-	±20ppm	9pF	70 kOhms
ST3215SB32768H5HSZA1	日產京瓷晶振	ST3215SB	32.768 kHz	-	±20ppm	12.5pF	70 kOhms
CX2520DB16000D0WZRC1	日產京瓷晶振	CX2520DB	16 MHz	±50ppm	±25ppm	8pF	80 Ohms
CX2520DB32000D0WZRC1	日產京瓷晶振	CX2520DB	32 MHz	±50ppm	±25ppm	8pF	50 Ohms
ST2012SB32768H5WZZAP	日產京瓷晶振	ST2012SB	32.768 kHz	-	±250ppm	12.5pF	75 kOhms
ST3215SB32768H5WZZAP	日產京瓷晶振	ST3215SB	32.768 kHz	±250ppm	-	12.5pF	70 kOhms
CX5032GA08000H0PST02	日產京瓷晶振	CX5032GA	8 MHz	±100ppm	±50ppm	12pF	200 Ohms
CX8045GA04000H0PST03	日產京瓷晶振	CX8045GA	4 MHz	±100ppm	±50ppm	12pF	300 Ohms
CX2016DB16000H0FLJC1	日產京瓷晶振	CX2016DB	16 MHz	±15ppm	±10ppm	12pF	200 Ohms
CX2520DB12000D0FLJC1	日產京瓷晶振	CX2520DB	12 MHz	±15ppm	±10ppm	8pF	150 Ohms
CX2520DB12000H0FLJC1	日產京瓷晶振	CX2520DB	12 MHz	±15ppm	±10ppm	12pF	150 Ohms
CX2520DB13560D0FLJC2	日產京瓷晶振	CX2520DB	13.56 MHz	±15ppm	±10ppm	8pF	150 Ohms
CX2520DB13560H0FLJC1	日產京瓷晶振	CX2520DB	13.56 MHz	±15ppm	±10ppm	12pF	150 Ohms
CX2520DB16000H0FLJC1	日產京瓷晶振	CX2520DB	16 MHz	±15ppm	±10ppm	12pF	80 Ohms
CX2520DB16000D0GPSC1	日產京瓷晶振	CX2520DB	16 MHz	±50ppm	±15ppm	8pF	80 Ohms
CX2520DB19200D0FLJC2	日產京瓷晶振	CX2520DB	19.2 MHz	±15ppm	±10ppm	8pF	80 Ohms
CX2520DB19200H0FLJC1	日產京瓷晶振	CX2520DB	19.2 MHz	±15ppm	±10ppm	12pF	80 Ohms
CX2520DB24000D0FLJCC	日產京瓷晶振	CX2520DB	24 MHz	±15ppm	±10ppm	8pF	80 Ohms
CX2520DB24000H0FLJC1	日產京瓷晶振	CX2520DB	24 MHz	±15ppm	±10ppm	12pF	80 Ohms
CX2520DB25000D0FLJC1	日產京瓷晶振	CX2520DB	25 MHz	±15ppm	±10ppm	8pF	80 Ohms
CX2520DB25000H0FLJC1	日產京瓷晶振	CX2520DB	25 MHz	±15ppm	±10ppm	12pF	80 Ohms
CX2520DB27000H0FLJC1	日產京瓷晶振	CX2520DB	27 MHz	±15ppm	±10ppm	12pF	60 Ohms
CX2520DB32000H0FLJC1	日產京瓷晶振	CX2520DB	32 MHz	±15ppm	±10ppm	12pF	50 Ohms
CX2520DB40000D0GPSC1	日產京瓷晶振	CX2520DB	40 MHz	±50ppm	±15ppm	8pF	50 Ohms
CX2520DB12000D0GPSC1	日產京瓷晶振	CX2520DB	12 MHz	±50ppm	±15ppm	8pF	150 Ohms
CX2520DB13560D0GPSC1	日產京瓷晶振	CX2520DB	13.56 MHz	±50ppm	±15ppm	8pF	150 Ohms
CX2520DB19200D0GPSC1	日產京瓷晶振	CX2520DB	19.2 MHz	±50ppm	±15ppm	8pF	80 Ohms
CX2520DB20000H0FLJC1	日產京瓷晶振	CX2520DB	20 MHz	±15ppm	±10ppm	12pF	80 Ohms
CX2520DB20000D0GPSC1	日產京瓷晶振	CX2520DB	20 MHz	±50ppm	±15ppm	8pF	80 Ohms
CX2520DB24000D0GPSC1	日產京瓷晶振	CX2520DB	24 MHz	±50ppm	±15ppm	8pF	80 Ohms
CX2520DB24576D0FLJC1	日產京瓷晶振	CX2520DB	24.576 MHz	±15ppm	±10ppm	8pF	80 Ohms
CX2520DB24576H0FLJC1	日產京瓷晶振	CX2520DB	24.576 MHz	±15ppm	±10ppm	12pF	80 Ohms
CX2520DB24576D0GPSC1	日產京瓷晶振	CX2520DB	24.576 MHz	±50ppm	±15ppm	8pF	80 Ohms
CX2520DB25000D0GPSC1	日產京瓷晶振	CX2520DB	25 MHz	±50ppm	±15ppm	8pF	80 Ohms
